PP High Quality Non-woven Geotextile Fabric For Waterproofing
PP non-woven fabric is made of polypropylene fibers through processes such as hot melting, spraying, and high-speed air flow to form a network structure, and then undergoes appropriate heat setting, compaction and other processing processes.
1. Has high tensile strength and good anti-penetration performance
2. Can effectively enhance the stability and bearing capacity of soil
3. Excellent backflow resistance
4. Can prevent soil particles from being washed away or eroded
5. Has good anti-aging properties and chemical corrosion resistance
Polypropylene nonwoven geotextile, referred to as PP geotextile, it is a non-woven fabric made of polypropylene fiber as the main raw material.
Material: PP
Weight:100-800g
Width: 1-7m
Length: 50-200m (customizable)
Color; white, black, orange, supports custom colors
Features:
1. Lightweight and immoderate strength: PP geotextile has slight weight and first-rate tensile strength, can stand up to huge hundreds and extrusion forces in projects, and has pinnacle durability.
2. Good acid and alkali resistance: PP geotextile can face up to the erosion and corrosion of a variety chemical factors such as acids, alkalis, salts, etc., and is terrific for wonderful soil environments.
3. Good local weather resistance: PP geotextile has proper local weather resistance, can face up to ultraviolet radiation and the results of nearby climate change, and hold impervious normal overall performance of the material.
4. Good water and air permeability: The ground of PP geotextile regularly has a particular pore structure, which can collect pinnacle water and air permeability and keep soil moisture and gasoline exchange.
5. Good environmental protection: PP geotextile is made of environmentally exceptional materials and is non-toxic, odorless and degradable, and will no longer pollute the environment.
Application:
1. Water conservancy projects: PP geotextiles are fabulous for anti-penetration, landslide resistance, and erosion resistance in rivers, reservoirs, and dams in water conservancy projects.
2. Foundation engineering: PP geotextiles can be used for soil reinforcement, leakage prevention and soil conservation to decorate the stability and reliability of groundwork engineering.
3. Road engineering: PP geotextile can be used to improve and stabilize roadbeds and pavements, limit the incidence of pavement cracks and settlements, and lengthen the service existence of roads.
4. Mines and landfills: PP geotextiles can be used for whole administration of mines and reinforcement and anti-seepage of landfills to limit soil and groundwater pollution.
5. Agricultural engineering: PP geotextile can be used in agricultural engineering such as windproof and warmness preservation, soil moisture retention and soil care to promote crop make bigger and prolong yield.
Specifications:
| Staple Fiber Needled Non-woven Geotextile Technical Specifications ( GB/T17638-2017) | |||||||||||
| No. | Item | Specifications | Note | ||||||||
| 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | |||
| 1 | Thickness mm≥ | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3.0 | 3.3 | 3.6 | |
| 2 | Width deviation | -0.5 | |||||||||
| 3 | Standard breaking strength/（KN*m） | 3 | 5 | 8 | 10 | 15 | 20 | 25 | 30 | 40 | Vertical and horizontal |
| 4 | Elongation at break % | 20-100 | |||||||||
| 5 | CBR bursting strength/KN | 0.6 | 1 | 1.4 | 1.8 | 2.5 | 3.2 | 4 | 5.5 | 7 | |
| 6 | Equivalent aperture | 0.07-0.2 | |||||||||
| 7 | Vertical permeability coefficient | K*（10-1～10-3） | K=1.0-9.9 | ||||||||
| 8 | Longitudinal and transverse tear strength/KN | 0.1 | 0.15 | 0.2 | 0.25 | 0.4 | 0.5 | 0.65 | 0.8 | 1 | Vertical and horizontal |
| 9 | Acid and alkali resistance/% ≥ | 80% | |||||||||
| 10 | Antioxidant properties/% ≥ | 80% | |||||||||
| 9 | UV resistance% ≥ | 80% | |||||||||
