Customization Geotextile Needle Punched Nonwoven Fabric
Non-woven geotextiles have the advantages of good water permeability, high tensile strength, strong pressure resistance, and resistance to acid and alkali corrosion.
It can be used in soil reinforcement, waterproofing, filtration, isolation, protection and other fields.
Non-woven geotextiles are produced using non-woven technology.PP/PET high-strength non-woven geotextile for construction
Material: PET/PP
Weight:100-800g
Width: 1-7m
Length: 50-200m (customizable)
Color; white, black, orange, supports custom colors
Non-woven geotextiles have the advantages of simple structure, stable performance, and easy use.
Features:
1. High strength: Non-woven geotextiles use superb manufacturing techniques and supplies to supply them extraordinarily correct tensile strength, rupture resistance and puncture resistance.
2. Good local weather resistance: The synthetic material fabric used in non-woven geotextile has authentic local weather resistance and can be used for a prolonged time under distinct neighborhood climate conditions.
3. Good acid and alkali resistance: Non-woven geotextile can face up to the erosion of chemical resources such as acids and alkali, making certain its long-term stability and reliability.
4. Good water permeability and air permeability: The flooring of non-woven geotextiles generally has immoderate water permeability and air permeability, which can preserve the circulation of groundwater and soil breathing.
5. Good anti-aging properties: The non-woven geotextile is delivered with one-of-a-kind anti-aging additives, which can stand up to ultraviolet erosion and extend its service life.
Application:
1.Water conservancy projects: Non-woven geotextiles can be used for anti-seepage, anti-leakage, soil conservation and anti-scouring in reservoirs, rivers, dams and distinctive projects.
2.Road engineering: Non-woven geotextiles can be used to red meat up and stabilize roadbeds, limit the incidence of avenue fall down and cracks, and increase the service existence of roads.
3.Yard and wharf projects: Non-woven geotextiles can be used for soil conservation, anti-leakage, load-bearing potential improvement, etc. to make greater the effectivity and safety of yard and wharf projects.
4.Environmental engineering: Non-woven geotextiles can be used for anti-penetration and air air pollution manipulate on the bottom and sides of landfills, waste disposal sites, etc.
5.Agricultural engineering: Non-woven geotextiles can be used for soil moisture retention and windproof insulation to promote crop expand and make bigger yields.
Specifications:
| Filament Spunbonded Needled Non-woven Geotextile Technical Specifications | ||||||||||
| Item | Index | |||||||||
| Index breaking strength（KN/m） | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | |
| 1 | Vertical and horizontal rupture strength / (KN/ m) | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 |
| 2 | Vertical and horizontal standard strength corresponding to elongation % | 40-80 | ||||||||
| 3 | CBR bursting strength /KN | 0.8 | 1.6 | 1.9 | 2.9 | 3.9 | 5.3 | 6.4 | 7.9 | 8.5 |
| 4 | Vertical and horizontal tearing strength /KN | 0.14 | 0.21 | 0.28 | 0.42 | 0.56 | 0.70 | 0.82 | 1.10 | 1.25 |
| 5 | Equivalent aperture O90(95)>/mm | 0.05-0.20 | ||||||||
| 6 | Vertical permeability coefficient | K*(10-1～10-3）and K=1.0～9.9 | ||||||||
| 7 | Thickness / mm≥ | 0.8 | 1.2 | 1.6 | 2.2 | 2.8 | 3.4 | 4.2 | 5.5 | 6.8 |
| 8 | Width deviation | -0.5 | ||||||||
| 9 | Unit area mass deviation | -5 | ||||||||
