Geomembrane Fish Pond Liner

HDPE geomembrane is produced by three-layer co-blowing process or calendering process. It is an effective waterproof barrier engineering material.

1. Excellent anti-penetration performance, waterproof, anti-seepage and isolation

2.High chemical corrosion resistance

3. Better impact resistance and wear resistance

Contact Now E-Mail Telephone WhatsApp

Product Details

HDPE geomembrane is a geotechnical material made of high-density polyethylene.

Material: HDPE

Thickness: 0.2-3mm

Width: 1-8m

Length: according to customer needs

Features:

1. Resistant to chemical corrosion: HDPE geomembrane has excellent resistance to chemical corrosion such as acids, alkalis, salts, etc., and is suitable for various soil environments.

2. High strength: HDPE geomembrane has excellent tensile strength and tear resistance and can withstand large loads and extrusion forces in projects.

3. Good durability: HDPE geomembrane has good weather resistance, can resist ultraviolet radiation and the effects of climate change, and maintain stable performance of the material.

4. Poor water permeability: HDPE geomembrane is basically impermeable, can achieve effective anti-penetration and isolation effects, and is suitable for projects that require anti-penetration.

5. Good environmental protection: HDPE geomembrane is made of environmentally friendly materials. It is non-toxic, odorless and recyclable, and will not cause pollution to the environment.

Geomembrane Fish Pond Liner

Application:

1. Water conservancy projects: HDPE geomembrane is appropriate for the development of anti-seepage and isolation layers in channels, reservoirs, anti-seepage walls, etc. in water conservancy projects.
2. Soil air pollution prevention and control: HDPE geomembrane can be used as the isolation layer at the backside and facets of soil air pollution prevention and manage initiatives to stop the penetration and unfold of pollutants.
3. Basic engineering: HDPE geomembrane can be used as a water-resistant isolation layer in basements, underground cities and different fundamental projects.
4. Artificial lakes and breeding: HDPE geomembrane can be used as the anti-permeability layer in synthetic lakes, pools, breeding and other locations to make certain that the water physique does now not leak and seep.
5. Landfills: HDPE geomembranes can be used as anti-seepage layers in landfills to stop waste leakage and groundwater pollution.

Geomembrane Fish Pond Liner

Specifications:

HDPE Geomembrane Technical Parameter (GRI GM13 ASTM Standard)
Spec Properties	Test method ASTM	GMS0.2	GMS0.5	GMS0.75	GMS1.0	GMS1.25	GMS1.5	GMS2.0	GMS2.5	GMS3.0
Thickness	D5199	0.2mm	0.5mm	0.75mm	1.00mm	1 .25mm	1.50mm	2.00mm	2.50mm	3.00mm
Density (≥ g/cc)	D1505	0.94	0.940	0.940	0.940	0.940	0.940	0.940	0.940	0.94
Tensile Properties (Each direction)(≥) • yield strength • break strength • yield elongation • break elongation	D6693 Type IV	3 kN/m 5 kN/m 12% 700%	8 kN/m 14 kN/m 12% 700%	11 kN/m 20 kN/m 12% 700%	15 kN/m 27 kN/m 12% 700%	18 kN/m 33 kN/m 12% 700%	22 kN/m 40 kN/m 12% 700%	29kN/m 53 KN/m 12% 700%	37kN/m 67kN/m 12% 700%	44kN/m 80kN/m 12% 700%
Tear Resistance (≥)	D 1004	25N	64N	93N	125 N	156N	187N	249 N	311 N	374 N
Puncture Resistance(≥)	D 4833	64N	160N	240N	320 N	400 N	480N	640 N	800 N	960 N
Stress Crack Resistance (≥)	D 5397	500 hr	500 hr	500 hr	500 hr	500 hr	500 hr	500 hr	500 hr	500 hr
Carbon Black Content	D 1603	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%
Carbon Black Dispersion	D 5596	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)
Oxidative Induction Time(OIT)(≥) (a)Standard OIT ——or—— (b)High Pressure OIT	D 3895 D 5885	100min 500min	100 min 500 min	100 min 500 min	100 min 500 min	100 min 500 min	100 min 500 min	100 min 500 min	100 min 500 min	100 min 500 min
